Description
FIXED IND 15UH 6A 14 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTH8HCF-150K.
CTH8HCF-150K has an inductance value of 15 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTH8HCF-150K is rated for 6 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTH8HCF-150K lists a DC resistance of 14mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTH8HCF-150K uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTH8HCF-150K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 15 µH |
| Tolerance | ±10% |
| Current Rating | 6 A |
| DC Resistance (DCR) | 14mOhm Max |
| Saturation Current | 14.8A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.550 Dia x 1.000 L (13.97mm x 25.40mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Central Technologies |
| Description | FIXED IND 15UH 6A 14 MOHM TH |
| Series | CTH8HCF |
| Product Status | Active |
| Type / Construction | - |
| Core Material | - |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
| Height - Seated (Max) | - |
| Features | - |
