Description
FIXED IND 125UH 80 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTH9F-125M.
CTH9F-125M has an inductance value of 125 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTH9F-125M is rated for -. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTH9F-125M lists a DC resistance of 80mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTH9F-125M uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTH9F-125M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 125 µH |
| Tolerance | ±20% |
| Current Rating | - |
| DC Resistance (DCR) | 80mOhm Max |
| Saturation Current | 3.5A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.500 Dia x 1.250 L (12.70mm x 31.75mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Central Technologies |
| Description | FIXED IND 125UH 80 MOHM TH |
| Series | CTH9F |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
| Height - Seated (Max) | - |
| Features | - |
