Description
FIXED IND 1UH 8.6A 13 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTIHSM4825F-1R0L.
CTIHSM4825F-1R0L has an inductance value of 1 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTIHSM4825F-1R0L is rated for 8.6 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTIHSM4825F-1R0L lists a DC resistance of 13mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTIHSM4825F-1R0L uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTIHSM4825F-1R0L to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1 µH |
| Tolerance | ±15% |
| Current Rating | 8.6 A |
| DC Resistance (DCR) | 13mOhm Max |
| Saturation Current | 4.1A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.520 L x 0.250 W (13.20mm x 6.35mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Central Technologies |
| Description | FIXED IND 1UH 8.6A 13 MOHM SMD |
| Series | CTIHSM4825F |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | - |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | SMD |
| Height - Seated (Max) | 0.230 (5.84mm) |
| Features | - |
