Description
FIXED IND 220UH 460MA 1.58 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTIHSM4825F-221L.
CTIHSM4825F-221L has an inductance value of 220 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTIHSM4825F-221L is rated for 460 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTIHSM4825F-221L lists a DC resistance of 1.58Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTIHSM4825F-221L uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTIHSM4825F-221L to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 220 µH |
| Tolerance | ±15% |
| Current Rating | 460 mA |
| DC Resistance (DCR) | 1.58Ohm Max |
| Saturation Current | 320mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.520 L x 0.250 W (13.20mm x 6.35mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Central Technologies |
| Description | FIXED IND 220UH 460MA 1.58 OHM |
| Series | CTIHSM4825F |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | - |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | SMD |
| Height - Seated (Max) | 0.230 (5.84mm) |
| Features | - |
