Description
FIXED IND 1.5MH 170MA 7.35 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTIHSM5832F-152K.
CTIHSM5832F-152K has an inductance value of 1.5 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTIHSM5832F-152K is rated for 170 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTIHSM5832F-152K lists a DC resistance of 7.35Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTIHSM5832F-152K uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTIHSM5832F-152K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.5 mH |
| Tolerance | ±10% |
| Current Rating | 170 mA |
| DC Resistance (DCR) | 7.35Ohm Max |
| Saturation Current | 290mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.638 L x 0.320 W (16.20mm x 8.13mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Central Technologies |
| Description | FIXED IND 1.5MH 170MA 7.35 OHM |
| Series | CTIHSM5832F |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | - |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | SMD |
| Height - Seated (Max) | 0.285 (7.24mm) |
| Features | - |
