Description
FIXED IND 18UH 1.5A 83 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTIHSM5832F-180K.
CTIHSM5832F-180K has an inductance value of 18 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTIHSM5832F-180K is rated for 1.5 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTIHSM5832F-180K lists a DC resistance of 83mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTIHSM5832F-180K uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTIHSM5832F-180K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 18 µH |
| Tolerance | ±10% |
| Current Rating | 1.5 A |
| DC Resistance (DCR) | 83mOhm Max |
| Saturation Current | 3.2A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.638 L x 0.320 W (16.20mm x 8.13mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Central Technologies |
| Description | FIXED IND 18UH 1.5A 83 MOHM SMD |
| Series | CTIHSM5832F |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | - |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | SMD |
| Height - Seated (Max) | 0.285 (7.24mm) |
| Features | - |
