Description
FIXED IND 390UH 340MA 1.89 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTIHSM5832F-391K.
CTIHSM5832F-391K has an inductance value of 390 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTIHSM5832F-391K is rated for 340 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTIHSM5832F-391K lists a DC resistance of 1.89Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTIHSM5832F-391K uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTIHSM5832F-391K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 390 µH |
| Tolerance | ±10% |
| Current Rating | 340 mA |
| DC Resistance (DCR) | 1.89Ohm Max |
| Saturation Current | 540mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.638 L x 0.320 W (16.20mm x 8.13mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Central Technologies |
| Description | FIXED IND 390UH 340MA 1.89 OHM |
| Series | CTIHSM5832F |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | - |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | SMD |
| Height - Seated (Max) | 0.285 (7.24mm) |
| Features | - |
