Description
FIXED IND 15UH 730MA 560 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTLV3012SF-150M.
CTLV3012SF-150M has an inductance value of 15 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTLV3012SF-150M is rated for 730 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTLV3012SF-150M lists a DC resistance of 560mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTLV3012SF-150M uses a package or case of 1212 (3030 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTLV3012SF-150M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 15 µH |
| Tolerance | ±20% |
| Current Rating | 730 mA |
| DC Resistance (DCR) | 560mOhm |
| Saturation Current | 720mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.118 L x 0.118 W (3.00mm x 3.00mm) |
| Case / Size | 1212 (3030 Metric) |
| Package / Case | 1212 (3030 Metric) |
| Supplier | Central Technologies |
| Description | FIXED IND 15UH 730MA 560 MOHM |
| Series | CTLV3012SF |
| Product Status | Active |
| Type / Construction | - |
| Core Material | - |
| Shielding | Shielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1212 |
| Height - Seated (Max) | 0.047 (1.20mm) |
| Features | - |
