Description
FIXED IND 270NH 960MA 160 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTM1F-R27H.
CTM1F-R27H has an inductance value of 270 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTM1F-R27H is rated for 960 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTM1F-R27H lists a DC resistance of 160mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTM1F-R27H uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTM1F-R27H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 270 nH |
| Tolerance | - |
| Current Rating | 960 mA |
| DC Resistance (DCR) | 160mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | 0.095 Dia x 0.250 L (2.41mm x 6.35mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Central Technologies |
| Description | FIXED IND 270NH 960MA 160 MOHM |
| Series | CTM1F |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Phenolic |
| Shielding | Unshielded |
| Q @ Frequency | 33 @ 25MHz |
| Self Resonant Frequency | 430MHz |
| Ratings | - |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
| Height - Seated (Max) | - |
| Features | - |
