Description
FIXED IND 10UH 335MA 900 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTM2F-100K.
CTM2F-100K has an inductance value of 10 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTM2F-100K is rated for 335 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTM2F-100K lists a DC resistance of 900mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTM2F-100K uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTM2F-100K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 10 µH |
| Tolerance | ±10% |
| Current Rating | 335 mA |
| DC Resistance (DCR) | 900mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | 0.156 Dia x 0.375 L (3.96mm x 9.52mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Central Technologies |
| Description | FIXED IND 10UH 335MA 900 MOHM TH |
| Series | CTM2F |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 55 @ 7.9MHz |
| Self Resonant Frequency | 45MHz |
| Ratings | - |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
| Height - Seated (Max) | - |
| Features | - |
