Description
FIXED IND 5.6UH 5MA 1.5 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTML0603F-5R6K.
CTML0603F-5R6K has an inductance value of 5.6 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTML0603F-5R6K is rated for 5 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTML0603F-5R6K lists a DC resistance of 1.5Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTML0603F-5R6K uses a package or case of 0603 (1608 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTML0603F-5R6K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 5.6 µH |
| Tolerance | ±10% |
| Current Rating | 5 mA |
| DC Resistance (DCR) | 1.5Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.063" L x 0.031" W (1.60mm x 0.80mm) |
| Case / Size | 0603 (1608 Metric) |
| Package / Case | 0603 (1608 Metric) |
| Supplier | Central Technologies |
| Description | FIXED IND 5.6UH 5MA 1.5 OHM SMD |
| Series | CTML0603F |
| Product Status | Active |
| Type / Construction | Multilayer |
| Core Material | Ferrite |
| Shielding | Shielded |
| Q @ Frequency | 35 @ 4MHz |
| Self Resonant Frequency | 22MHz |
| Ratings | - |
| Inductance Test Frequency | 4 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0603 |
| Height - Seated (Max) | 0.039" (1.00mm) |
| Features | - |
