Description
FIXED IND 180UH 261MA 2.4 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTP1330F-184K.
CTP1330F-184K has an inductance value of 180 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTP1330F-184K is rated for 261 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTP1330F-184K lists a DC resistance of 2.4Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTP1330F-184K uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTP1330F-184K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 180 µH |
| Tolerance | ±10% |
| Current Rating | 261 mA |
| DC Resistance (DCR) | 2.4Ohm Max |
| Saturation Current | 89mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.311 L x 0.128 W (7.90mm x 3.25mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Central Technologies |
| Description | FIXED IND 180UH 261MA 2.4 OHM |
| Series | CTP1330F |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | - |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | SMD |
| Height - Seated (Max) | 0.142 (3.60mm) |
| Features | - |
