Description
FIXED IND 1.2NH 700MA 100 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTTF0402F-1N2B.
CTTF0402F-1N2B has an inductance value of 1.2 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTTF0402F-1N2B is rated for 700 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTTF0402F-1N2B lists a DC resistance of 100mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTTF0402F-1N2B uses a package or case of 0402 (1005 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTTF0402F-1N2B to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.2 nH |
| Tolerance | ±0.1nH |
| Current Rating | 700 mA |
| DC Resistance (DCR) | 100mOhm Max |
| Saturation Current | - |
| Operating Temperature | -40°C ~ 85°C |
| Dimensions | 0.039 L x 0.020 W (1.00mm x 0.50mm) |
| Case / Size | 0402 (1005 Metric) |
| Package / Case | 0402 (1005 Metric) |
| Supplier | Central Technologies |
| Description | FIXED IND 1.2NH 700MA 100 MOHM |
| Series | CTTF0402F |
| Product Status | Active |
| Type / Construction | Thin Film |
| Core Material | - |
| Shielding | Unshielded |
| Q @ Frequency | 13 @ 500MHz |
| Self Resonant Frequency | 6GHz |
| Ratings | - |
| Inductance Test Frequency | 500 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0402 |
| Height - Seated (Max) | 0.016 (0.40mm) |
| Features | - |
