Description
FIXED IND 1.2MH 1.1A 550 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for DB2-124.
DB2-124 has an inductance value of 1.2 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
DB2-124 is rated for 1.1 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
DB2-124 lists a DC resistance of 550mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
DB2-124 uses a package or case of Radial, Vertical Cylinder (Open). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from DB2-124 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.2 mH |
| Tolerance | ±10% |
| Current Rating | 1.1 A |
| DC Resistance (DCR) | 550mOhm Max |
| Saturation Current | 2.7A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.800" Dia (20.32mm) |
| Case / Size | Radial, Vertical Cylinder (Open) |
| Package / Case | Radial, Vertical Cylinder (Open) |
| Supplier | Gowanda |
| Description | FIXED IND 1.2MH 1.1A 550 MOHM TH |
| Series | DB2 |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Radial |
| Height - Seated (Max) | 0.712" (18.08mm) |
