Description
FIXED IND 82UH 3.44A 83 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for DC630-823K.
DC630-823K has an inductance value of 82 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
DC630-823K is rated for 3.44 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
DC630-823K lists a DC resistance of 83mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
DC630-823K uses a package or case of Radial, Vertical Cylinder. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from DC630-823K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 82 µH |
| Tolerance | ±10% |
| Current Rating | 3.44 A |
| DC Resistance (DCR) | 83mOhm Max |
| Saturation Current | 7.6A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.630" Dia (16.00mm) |
| Case / Size | Radial, Vertical Cylinder |
| Package / Case | Radial, Vertical Cylinder |
| Supplier | Delevan |
| Description | FIXED IND 82UH 3.44A 83 MOHM TH |
| Series | DC630 |
| Product Status | Active |
| Type / Construction | Wirewound |
| Shielding | Unshielded |
| Inductance Test Frequency | 10 kHz |
| Mounting Type | Through Hole |
| Height - Seated (Max) | 0.830" (21.08mm) |
