FIXED IND 120NH 53A 0.47 MOHM
| Inductance | 120 nH |
| Tolerance | ±10% |
| Current Rating | 53 A |
| DC Resistance (DCR) | 0.47mOhm |
| saturationCurrent | 87A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.579" L x 0.264" W (14.70mm x 6.70mm) |
| Case / Size | Nonstandard |
| Supplier | Eaton - Electronics Division |
| Description | FIXED IND 120NH 53A 0.47 MOHM |
| Series | FLAT-PAC, FP1505 |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Unshielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.197" (5.00mm) |
| features | - |
