Description
FIXED IND 100MH 36MA 210 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for GA10-106K.
GA10-106K has an inductance value of 100 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
GA10-106K is rated for 36 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
GA10-106K lists a DC resistance of 210Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
GA10-106K uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from GA10-106K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 100 mH |
| Tolerance | ±10% |
| Current Rating | 36 mA |
| DC Resistance (DCR) | 210Ohm Max |
| Saturation Current | 23mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.260" Dia x 0.630" L (6.60mm x 16.00mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Gowanda |
| Description | FIXED IND 100MH 36MA 210 OHM |
| Series | GA10 |
| Product Status | Active |
| Type / Construction | Toroidal |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Self Resonant Frequency | 74kHz |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
