FIXED IND 100MH 20MA 420 OHM TH
| Inductance | 100 mH |
| Tolerance | ±5% |
| Current Rating | 20 mA |
| DC Resistance (DCR) | 420Ohm Max |
| saturationCurrent | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) |
| Case / Size | Axial |
| Supplier | TDK |
| Description | FIXED IND 100MH 20MA 420 OHM TH |
| Series | LBC |
| productStatus | Last Time Buy |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Unshielded |
| qFactor | 30 @ 79.6kHz |
| selfResonantFreq | 120kHz |
| ratings | - |
| testFrequency | 10 kHz |
| mountingType | Through Hole |
| supplierDevicePackage | - |
| heightMax | - |
| features | - |
