FIXED IND 4.2UH 9.83A 7.9 MOHM
| Inductance | 4.2 µH |
| Tolerance | ±20% |
| Current Rating | 9.83 A |
| DC Resistance (DCR) | 7.9mOhm Max |
| saturationCurrent | - |
| Operating Temperature | -30°C ~ 130°C |
| Dimensions | 0.615" L x 0.615" W (15.62mm x 15.62mm) |
| Case / Size | Nonstandard |
| Supplier | Gowanda |
| Description | FIXED IND 4.2UH 9.83A 7.9 MOHM |
| Series | HCSM |
| productStatus | Active |
| typeConstruction | Toroidal |
| coreMaterial | - |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | 100MHz |
| ratings | - |
| testFrequency | 1 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.370" (9.40mm) |
| features | - |
