FIXED IND 3.5UH 8.5A 16.5 MOHM
| Inductance | 3.5 µH |
| Tolerance | ±20% |
| Current Rating | 8.5 A |
| DC Resistance (DCR) | 16.5mOhm Max |
| saturationCurrent | 15.3A |
| Operating Temperature | -40°C ~ 155°C |
| Dimensions | 0.429" L x 0.409" W (10.90mm x 10.40mm) |
| Case / Size | Nonstandard |
| Supplier | Eaton - Electronics Division,WEC |
| Description | FIXED IND 3.5UH 8.5A 16.5 MOHM |
| Series | HC8 |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Iron Powder |
| shielding | Unshielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.157" (4.00mm) |
| features | - |
