FIXED IND 1.5UH 12A 6 MOHM SMD
| Inductance | 1.5 µH |
| Tolerance | ±10% |
| Current Rating | 12 A |
| DC Resistance (DCR) | 6mOhm |
| saturationCurrent | 21A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.480" L x 0.386" W (12.20mm x 9.80mm) |
| Case / Size | Nonstandard |
| Supplier | Eaton - Electronics Division |
| Description | FIXED IND 1.5UH 12A 6 MOHM SMD |
| Series | HCV1206 |
| productStatus | Active |
| typeConstruction | - |
| coreMaterial | Ferrite |
| shielding | Unshielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.201" (5.10mm) |
| features | - |
