Description
FIXED IND 330UH 160MA 3.8 OHM
Specifications
Inductance
330 µH
Current Rating
160 mA
DC Resistance (DCR)
3.8Ohm Max
Dimensions
0.260" L x 0.175" W (6.60mm x 4.45mm)
Parameter Guide
Understand the key electrical and mechanical specifications for IDC2512ER331M.
Inductance
330 µH
IDC2512ER331M has an inductance value of 330 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
Current Rating
160 mA
IDC2512ER331M is rated for 160 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
DC Resistance (DCR)
3.8Ohm Max
IDC2512ER331M lists a DC resistance of 3.8Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
Explore Related Datasheet Paths
Continue from IDC2512ER331M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 330 µH |
| Tolerance | ±20% |
| Current Rating | 160 mA |
| DC Resistance (DCR) | 3.8Ohm Max |
| Saturation Current | 180mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.260" L x 0.175" W (6.60mm x 4.45mm) |
| Supplier | Vishay Dale |
| Description | FIXED IND 330UH 160MA 3.8 OHM |
| Series | IDC-2512 |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.115" (2.92mm) |
