Description
FIXED IND 68UH 400MA 860 MOHM
Specifications
Inductance
68 µH
Current Rating
400 mA
DC Resistance (DCR)
860mOhm Max
Dimensions
0.260" L x 0.175" W (6.60mm x 4.45mm)
Parameter Guide
Understand the key electrical and mechanical specifications for IDC2512ER680M.
Inductance
68 µH
IDC2512ER680M has an inductance value of 68 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
Current Rating
400 mA
IDC2512ER680M is rated for 400 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
DC Resistance (DCR)
860mOhm Max
IDC2512ER680M lists a DC resistance of 860mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
Explore Related Datasheet Paths
Continue from IDC2512ER680M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 68 µH |
| Tolerance | ±20% |
| Current Rating | 400 mA |
| DC Resistance (DCR) | 860mOhm Max |
| Saturation Current | 400mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.260" L x 0.175" W (6.60mm x 4.45mm) |
| Supplier | Vishay Dale |
| Description | FIXED IND 68UH 400MA 860 MOHM |
| Series | IDC-2512 |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.115" (2.92mm) |
