FIXED IND 47UH 1.45A 120 MOHM
| Inductance | 47 µH |
| Tolerance | ±15% |
| Current Rating | 1.45 A |
| DC Resistance (DCR) | 120mOhm Max |
| saturationCurrent | 1A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.475" L x 0.420" W (12.07mm x 10.67mm) |
| Case / Size | Nonstandard |
| Supplier | Delevan |
| Description | FIXED IND 47UH 1.45A 120 MOHM |
| Series | LLST |
| productStatus | Obsolete |
| typeConstruction | Toroidal |
| coreMaterial | Nickel Iron |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | 10MHz |
| ratings | - |
| testFrequency | 1 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.290" (7.37mm) |
