Description
FIXED IND 390UH 680MA 770 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for M27/370-32.
M27/370-32 has an inductance value of 390 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
M27/370-32 is rated for 680 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
M27/370-32 lists a DC resistance of 770mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
M27/370-32 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from M27/370-32 to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 390 µH |
| Tolerance | ±15% |
| Current Rating | 680 mA |
| DC Resistance (DCR) | 770mOhm Max |
| Saturation Current | 320mA |
| Operating Temperature | -55°C ~ 130°C |
| Dimensions | 0.880" L x 0.330" W (22.35mm x 8.38mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Delevan |
| Description | FIXED IND 390UH 680MA 770 MOHM |
| Series | Military, MIL-PRF-27/370, MIL8532 |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.286" (7.26mm) |
