Description
FIXED IND 3.3UH 120MA 400 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MCL2012V1-3R3-R.
MCL2012V1-3R3-R has an inductance value of 3.3 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MCL2012V1-3R3-R is rated for 120 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MCL2012V1-3R3-R lists a DC resistance of 400mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MCL2012V1-3R3-R uses a package or case of 0805 (2012 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MCL2012V1-3R3-R to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 3.3 µH |
| Tolerance | ±20% |
| Current Rating | 120 mA |
| DC Resistance (DCR) | 400mOhm Max |
| Operating Temperature | -40°C ~ 85°C |
| Dimensions | 0.079" L x 0.047" W (2.00mm x 1.20mm) |
| Case / Size | 0805 (2012 Metric) |
| Package / Case | 0805 (2012 Metric) |
| Supplier | Eaton - Electronics Division |
| Description | FIXED IND 3.3UH 120MA 400 MOHM |
| Series | MCL2012V1 |
| Product Status | Active |
| Type / Construction | Multilayer |
| Shielding | Unshielded |
| Self Resonant Frequency | 41MHz |
| Inductance Test Frequency | 1 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0805 |
| Height - Seated (Max) | 0.043" (1.10mm) |
