Description
FIXED IND 33NH 160MA 2.8 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MHQ0603P33NHTD25.
MHQ0603P33NHTD25 has an inductance value of 33 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MHQ0603P33NHTD25 is rated for 160 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MHQ0603P33NHTD25 lists a DC resistance of 2.8Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MHQ0603P33NHTD25 uses a package or case of 0201 (0603 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MHQ0603P33NHTD25 to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 33 nH |
| Tolerance | ±3% |
| Current Rating | 160 mA |
| DC Resistance (DCR) | 2.8Ohm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.026" L x 0.014" W (0.65mm x 0.35mm) |
| Case / Size | 0201 (0603 Metric) |
| Package / Case | 0201 (0603 Metric) |
| Supplier | TDK |
| Description | FIXED IND 33NH 160MA 2.8 OHM SMD |
| Series | MHQ-P |
| Product Status | Active |
| Type / Construction | Multilayer |
| Core Material | Ceramic, Non-Magnetic |
| Shielding | Unshielded |
| Q @ Frequency | 14 @ 300MHz |
| Self Resonant Frequency | 1.8GHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 300 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0201 (0603 Metric) |
| Height - Seated (Max) | 0.016" (0.40mm) |
