Description
FIXED IND 18UH 400MA 875 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MLP1812-182K.
MLP1812-182K has an inductance value of 18 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MLP1812-182K is rated for 400 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MLP1812-182K lists a DC resistance of 875mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MLP1812-182K uses a package or case of 1812 (4532 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MLP1812-182K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 18 µH |
| Tolerance | ±10% |
| Current Rating | 400 mA |
| DC Resistance (DCR) | 875mOhm Max |
| Saturation Current | 614mA |
| Operating Temperature | -55°C ~ 130°C |
| Dimensions | 0.178" L x 0.126" W (4.53mm x 3.20mm) |
| Case / Size | 1812 (4532 Metric) |
| Package / Case | 1812 (4532 Metric) |
| Supplier | Gowanda |
| Description | FIXED IND 18UH 400MA 875 MOHM |
| Series | MLP1812 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1812 |
| Height - Seated (Max) | 0.138" (3.51mm) |
| Features | - |
