Description
FIXED IND 3.9UH 3.07A 42 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MLP5025-391L.
MLP5025-391L has an inductance value of 3.9 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MLP5025-391L is rated for 3.07 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MLP5025-391L lists a DC resistance of 42mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MLP5025-391L uses a package or case of 0.505" L x 0.240" W (12.82mm x 6.09mm). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MLP5025-391L to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 3.9 µH |
| Tolerance | ±15% |
| Current Rating | 3.07 A |
| DC Resistance (DCR) | 42mOhm Max |
| Saturation Current | 3.07A |
| Operating Temperature | -55°C ~ 130°C |
| Dimensions | 0.230" (5.84mm) |
| Supplier | Gowanda |
| Description | FIXED IND 3.9UH 3.07A 42 MOHM |
| Series | MLP5025 |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Mounting Type | Nonstandard |
| Supplier Device Package | 0.505" L x 0.240" W (12.82mm x 6.09mm) |
| Height - Seated (Max) | 1 kHz |
| Features | Surface Mount |
