Description
FIXED IND 3.9UH 1.6 OHM SMD
Specifications
Inductance
3.9 µH
Current Rating
430 mA Max
DC Resistance (DCR)
1.6Ohm
Parameter Guide
Understand the key electrical and mechanical specifications for CT0603LSF-392J.
Inductance
3.9 µH
CT0603LSF-392J has an inductance value of 3.9 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
Current Rating
430 mA Max
CT0603LSF-392J is rated for 430 mA Max. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
DC Resistance (DCR)
1.6Ohm
CT0603LSF-392J lists a DC resistance of 1.6Ohm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
Explore Related Datasheet Paths
Continue from CT0603LSF-392J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 3.9 µH |
| Tolerance | ±5% |
| Current Rating | 430 mA Max |
| DC Resistance (DCR) | 1.6Ohm |
| Operating Temperature | -40°C ~ 85°C |
| Supplier | Central Technologies |
| Description | FIXED IND 3.9UH 1.6 OHM SMD |
| Series | ct0603lsf |
| Product Status | Active |
| Type / Construction | Wirewound |
| Self Resonant Frequency | 80MHz |
| Mounting Type | Surface Mount |
