Description
FIXED IND 2.2UH 2A 140 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MPIA2010V1-2R2-R.
MPIA2010V1-2R2-R has an inductance value of 2.2 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MPIA2010V1-2R2-R is rated for 2 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MPIA2010V1-2R2-R lists a DC resistance of 140mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MPIA2010V1-2R2-R uses a package or case of 0806 (2016 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MPIA2010V1-2R2-R to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 2.2 µH |
| Tolerance | ±20% |
| Current Rating | 2 A |
| DC Resistance (DCR) | 140mOhm Max |
| Saturation Current | 2.2A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.079" L x 0.063" W (2.00mm x 1.60mm) |
| Case / Size | 0806 (2016 Metric) |
| Package / Case | 0806 (2016 Metric) |
| Supplier | Eaton - Electronics Division |
| Description | FIXED IND 2.2UH 2A 140 MOHM SMD |
| Series | MPIAV1 |
| Product Status | Active |
| Core Material | Alloy Powder |
| Shielding | Shielded |
| Self Resonant Frequency | 60MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 1 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0806 |
| Height - Seated (Max) | 0.039" (1.00mm) |
