Description
FIXED IND 44UH 6.2A 21.5 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PA2729.443NL.
PA2729.443NL has an inductance value of 44 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PA2729.443NL is rated for 6.2 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PA2729.443NL lists a DC resistance of 21.5mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PA2729.443NL uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PA2729.443NL to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 44 µH |
| Tolerance | ±15% |
| Current Rating | 6.2 A |
| DC Resistance (DCR) | 21.5mOhm Max |
| Saturation Current | 7.3A |
| Operating Temperature | -55°C ~ 130°C |
| Dimensions | 0.875" L x 0.750" W (22.23mm x 19.05mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 44UH 6.2A 21.5 MOHM |
| Series | PA2729.XXXNL |
| Product Status | Active |
| Type / Construction | Wirewound |
| Shielding | Shielded |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.480" (12.20mm) |
