FIXED IND 750NH 20A 3.5 MOHM SMD
| Inductance | 750 nH |
| Tolerance | ±20% |
| Current Rating | 20 A |
| DC Resistance (DCR) | 3.5mOhm Max |
| saturationCurrent | - |
| Operating Temperature | -40°C ~ 150°C |
| Dimensions | 0.465" L x 0.413" W (11.80mm x 10.50mm) |
| Case / Size | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 750NH 20A 3.5 MOHM SMD |
| Series | PM1038S |
| productStatus | Obsolete |
| typeConstruction | - |
| coreMaterial | Iron |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.165" (4.20mm) |
| features | - |
