Description
FIXED IND 330UH 1.69A 190 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PTKM330R-50H.
PTKM330R-50H has an inductance value of 330 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PTKM330R-50H is rated for 1.69 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PTKM330R-50H lists a DC resistance of 190mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PTKM330R-50H uses a package or case of Radial, Horizontal (Open). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PTKM330R-50H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 330 µH |
| Tolerance | ±10% |
| Current Rating | 1.69 A |
| DC Resistance (DCR) | 190mOhm Max |
| Saturation Current | 270mA |
| Dimensions | 0.625" Dia (15.87mm) |
| Case / Size | Radial, Horizontal (Open) |
| Package / Case | Radial, Horizontal (Open) |
| Supplier | Delevan |
| Description | FIXED IND 330UH 1.69A 190 MOHM |
| Series | PTKMR |
| Product Status | Active |
| Type / Construction | Toroidal |
| Core Material | Ferrite |
| Shielding | Shielded |
| Self Resonant Frequency | 1MHz |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Through Hole |
| Height - Seated (Max) | 0.300" (7.62mm) |
