Description
FIXED IND 50UH 9.9A 16 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PTKM50R-894VM.
PTKM50R-894VM has an inductance value of 50 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PTKM50R-894VM is rated for 9.9 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PTKM50R-894VM lists a DC resistance of 16mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PTKM50R-894VM uses a package or case of Radial, Vertical (Open). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PTKM50R-894VM to manufacturer, series, and broader datasheet collections.
Similar-specification candidates · Engineering review required
Screened against recorded construction, core, mounting, dimensions and current/DCR. Land pattern, test conditions and circuit compatibility still require validation.
Missing evidence or no candidates passed screening. A replacement cannot be determined; request a review of the original datasheets.
Product Attributes
| Inductance | 50 µH |
| Tolerance | ±10% |
| Current Rating | 9.9 A |
| DC Resistance (DCR) | 16mOhm Max |
| Saturation Current | 4.2A |
| Dimensions | 1.450" L x 0.825" W (36.83mm x 20.95mm) |
| Case / Size | Radial, Vertical (Open) |
| Package / Case | Radial, Vertical (Open) |
| Supplier | Delevan |
| Description | FIXED IND 50UH 9.9A 16 MOHM TH |
| Series | PTKMR-VM |
| Product Status | Active |
| Type / Construction | Toroidal |
| Core Material | Ferrite |
| Shielding | Shielded |
| Self Resonant Frequency | 4MHz |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Through Hole |
| Height - Seated (Max) | 1.475" (37.46mm) |
