FIXED IND 2.2UH 3.5A 45 MOHM SMD
| Inductance | 2.2 µH |
| Tolerance | ±30% |
| Current Rating | 3.5 A |
| DC Resistance (DCR) | 45mOhm Max |
| saturationCurrent | - |
| Operating Temperature | -40°C ~ 85°C |
| Dimensions | 0.500" L x 0.398" W (12.70mm x 10.10mm) |
| Case / Size | Nonstandard |
| Supplier | Delevan |
| Description | FIXED IND 2.2UH 3.5A 45 MOHM SMD |
| Series | SDS130R |
| productStatus | Obsolete |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 MHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.118" (3.00mm) |
| features | - |
