Description
FIXED IND 33UH 920MA 240 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SDS850R-333M.
SDS850R-333M has an inductance value of 33 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SDS850R-333M is rated for 920 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SDS850R-333M lists a DC resistance of 240mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SDS850R-333M uses a package or case of Surface Mount. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SDS850R-333M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 33 µH |
| Tolerance | ±20% |
| Current Rating | 920 mA |
| DC Resistance (DCR) | 240mOhm Max |
| Operating Temperature | -40°C ~ 85°C |
| Case / Size | Surface Mount |
| Package / Case | Surface Mount |
| Supplier | Delevan |
| Description | FIXED IND 33UH 920MA 240 MOHM |
| Series | SDS850R |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Inductance Test Frequency | 1 kHz |
| Supplier Device Package | Nonstandard |
| Height - Seated (Max) | 0.413" L x 0.315" W (10.50mm x 8.00mm) |
| Features | 0.189" (4.80mm) |
