FIXED IND 680UH 170MA 3.4 OHM
| Inductance | 680 µH |
| Tolerance | ±20% |
| Current Rating | 170 mA |
| DC Resistance (DCR) | 3.4Ohm Max |
| saturationCurrent | - |
| Operating Temperature | -40°C ~ 85°C |
| Dimensions | - |
| Case / Size | Surface Mount |
| Supplier | Delevan |
| Description | FIXED IND 680UH 170MA 3.4 OHM |
| Series | SDS850R |
| productStatus | Obsolete |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 1 kHz |
| mountingType | - |
| supplierDevicePackage | Nonstandard |
| heightMax | 0.413" L x 0.315" W (10.50mm x 8.00mm) |
| features | 0.189" (4.80mm) |
