Description
FIXED IND 5.6MH 96MA 38 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SMP3308-564M.
SMP3308-564M has an inductance value of 5.6 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SMP3308-564M is rated for 96 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SMP3308-564M lists a DC resistance of 38Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SMP3308-564M uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SMP3308-564M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 5.6 mH |
| Tolerance | ±20% |
| Current Rating | 96 mA |
| DC Resistance (DCR) | 38Ohm Max |
| Saturation Current | 125mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.530" L x 0.420" W (13.46mm x 10.67mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Gowanda |
| Description | FIXED IND 5.6MH 96MA 38 OHM SMD |
| Series | SMP3308 |
| Product Status | Active |
| Shielding | Unshielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.118" (3.00mm) |
