Description
FIXED IND 2.2MH 100MA 8.5 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRE6603-222M.
SRE6603-222M has an inductance value of 2.2 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRE6603-222M is rated for 100 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRE6603-222M lists a DC resistance of 8.5Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRE6603-222M uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRE6603-222M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 2.2 mH |
| Tolerance | ±20% |
| Current Rating | 100 mA |
| DC Resistance (DCR) | 8.5Ohm Max |
| Saturation Current | 28mA |
| Operating Temperature | -25°C ~ 105°C |
| Dimensions | 0.260" L x 0.175" W (6.60mm x 4.45mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 2.2MH 100MA 8.5 OHM |
| Series | SRE6603 |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Q @ Frequency | 50 @ 100kHz |
| Self Resonant Frequency | 2MHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.115" (2.92mm) |
