Description
FIXED IND 10UH 720MA 840 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRN2010BTA-100M.
SRN2010BTA-100M has an inductance value of 10 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRN2010BTA-100M is rated for 720 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRN2010BTA-100M lists a DC resistance of 840mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRN2010BTA-100M uses a package or case of 0806 (2016 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRN2010BTA-100M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 10 µH |
| Tolerance | ±20% |
| Current Rating | 720 mA |
| DC Resistance (DCR) | 840mOhm Max |
| Saturation Current | 620mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.079" L x 0.063" W (2.00mm x 1.60mm) |
| Case / Size | 0806 (2016 Metric) |
| Package / Case | 0806 (2016 Metric) |
| Supplier | Bourns Inc. |
| Description | FIXED IND 10UH 720MA 840 MOHM |
| Series | SRN2010BTA |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Semi-Shielded |
| Q @ Frequency | 10 @ 1MHz |
| Self Resonant Frequency | 28MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0806 |
| Height - Seated (Max) | 0.039" (1.00mm) |
