Description
FIXED IND 4UH 10.5A 5.4 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRP1205-4R0Y.
SRP1205-4R0Y has an inductance value of 4 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRP1205-4R0Y is rated for 10.5 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRP1205-4R0Y lists a DC resistance of 5.4mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRP1205-4R0Y uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRP1205-4R0Y to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 4 µH |
| Tolerance | ±25% |
| Current Rating | 10.5 A |
| DC Resistance (DCR) | 5.4mOhm Max |
| Saturation Current | 8.3A |
| Operating Temperature | -55°C ~ 150°C |
| Dimensions | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 4UH 10.5A 5.4 MOHM SMD |
| Series | SRP1205 |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Self Resonant Frequency | 35MHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.220" (5.60mm) |
