Description
FIXED IND 90NH 75A 0.125 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for TLVR1005T-90NK.
TLVR1005T-90NK has an inductance value of 90 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
TLVR1005T-90NK is rated for 75 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
TLVR1005T-90NK lists a DC resistance of 0.125mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
TLVR1005T-90NK uses a package or case of Nonstandard, 4 Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from TLVR1005T-90NK to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 90 nH |
| Tolerance | ±10% |
| Current Rating | 75 A |
| DC Resistance (DCR) | 0.125mOhm |
| Saturation Current | 98A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.382" L x 0.185" W (9.70mm x 4.70mm) |
| Case / Size | Nonstandard, 4 Lead |
| Package / Case | Nonstandard, 4 Lead |
| Supplier | Bourns Inc. |
| Description | FIXED IND 90NH 75A 0.125 MOHM |
| Series | TLVR1005T |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Ferrite |
| Shielding | Shielded |
| Mounting Type | Surface Mount |
| Supplier Device Package | Nonstandard, 4 Lead |
| Height - Seated (Max) | 0.472" (12.00mm) |
