Description
FIXED IND 1UH 450MA 300 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for WCL3225-1R0-R.
WCL3225-1R0-R has an inductance value of 1 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
WCL3225-1R0-R is rated for 450 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
WCL3225-1R0-R lists a DC resistance of 300mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
WCL3225-1R0-R uses a package or case of 1210 (3225 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from WCL3225-1R0-R to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1 µH |
| Tolerance | ±5% |
| Current Rating | 450 mA |
| DC Resistance (DCR) | 300mOhm Max |
| Operating Temperature | -40°C ~ 85°C |
| Dimensions | 0.138" L x 0.114" W (3.50mm x 2.90mm) |
| Case / Size | 1210 (3225 Metric) |
| Package / Case | 1210 (3225 Metric) |
| Supplier | Eaton - Electronics Division |
| Description | FIXED IND 1UH 450MA 300 MOHM SMD |
| Series | WCL3225 |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 12 @ 7.96MHz |
| Self Resonant Frequency | 320MHz |
| Inductance Test Frequency | 7.96 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1210 |
| Height - Seated (Max) | 0.089" (2.25mm) |
