FIXED IND 82UH 100MA 5.6 OHM SMD
| Inductance | 82 µH |
| Tolerance | ±5% |
| Current Rating | 100 mA |
| DC Resistance (DCR) | 5.6Ohm Max |
| saturationCurrent | - |
| Operating Temperature | -40°C ~ 85°C |
| Dimensions | 0.138" L x 0.114" W (3.50mm x 2.90mm) |
| Case / Size | 1210 (3225 Metric) |
| Supplier | WEC,Eaton - Electronics Division |
| Description | FIXED IND 82UH 100MA 5.6 OHM SMD |
| Series | WCL3225 |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ceramic |
| shielding | Unshielded |
| qFactor | 10 @ 2.52MHz |
| selfResonantFreq | 5MHz |
| ratings | - |
| testFrequency | 2.52 MHz |
| mountingType | Surface Mount |
| supplierDevicePackage | 1210 |
| heightMax | 0.089" (2.25mm) |
| features | - |
