Description
FIXED IND 33UH 95MA 5.2 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 0819-60J.
0819-60J has an inductance value of 33 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
0819-60J is rated for 95 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
0819-60J lists a DC resistance of 5.2Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
0819-60J uses a package or case of Through Hole. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 0819-60J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 33 µH |
| Tolerance | ±5% |
| Current Rating | 95 mA |
| DC Resistance (DCR) | 5.2Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | - |
| Case / Size | Through Hole |
| Package / Case | Through Hole |
| Supplier | Delevan |
| Description | FIXED IND 33UH 95MA 5.2 OHM TH |
| Series | 819 |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 45 @ 2.5MHz |
| Self Resonant Frequency | 15MHz |
| Ratings | - |
| Inductance Test Frequency | 2.5 MHz |
| Mounting Type | - |
| Supplier Device Package | Axial |
| Height - Seated (Max) | 0.078" Dia x 0.200" L (1.98mm x 5.08mm) |
| Features | - |
