Description
FIXED IND 1.2UH 591MA 430 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 1008-122H.
1008-122H has an inductance value of 1.2 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
1008-122H is rated for 591 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
1008-122H lists a DC resistance of 430mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
1008-122H uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 1008-122H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.2 µH |
| Tolerance | ±3% |
| Current Rating | 591 mA |
| DC Resistance (DCR) | 430mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.105" L x 0.095" W (2.66mm x 2.41mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Delevan |
| Description | FIXED IND 1.2UH 591MA 430 MOHM |
| Series | 1008 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 7.9MHz |
| Self Resonant Frequency | 100MHz |
| Ratings | - |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 |
| Height - Seated (Max) | 0.085" (2.16mm) |
