Description
FIXED IND 180UH 75MA 22 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 160R-184JS.
160R-184JS has an inductance value of 180 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
160R-184JS is rated for 75 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
160R-184JS lists a DC resistance of 22Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
160R-184JS uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 160R-184JS to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 180 µH |
| Tolerance | ±5% |
| Current Rating | 75 mA |
| DC Resistance (DCR) | 22Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.150" L x 0.120" W (3.81mm x 3.05mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Delevan |
| Description | FIXED IND 180UH 75MA 22 OHM SMD |
| Series | 160R |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 32 @ 790kHz |
| Self Resonant Frequency | 4.5MHz |
| Ratings | - |
| Inductance Test Frequency | 790 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.080" (2.03mm) |
