MPL-AL4020-4R7
Monolithic Power Systems Inc.
- Inductance
- 4.7 µH
- Current
- 3.65 A
- DCR
- 52.2mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
Inductor Datasheets
Browse and download PDF datasheets for inductors from leading manufacturers.
Series: MPL-AL
Browse series tables and compare the available specifications.
MPL-AL
MPL-AL4020-2R2
Monolithic Power Systems Inc.
- Inductance
- 2.2 µH
- Current
- 5.5 A
- DCR
- 21.5mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
MPL-AL4020-3R3
Monolithic Power Systems Inc.
- Inductance
- 3.3 µH
- Current
- 4.4 A
- DCR
- 34.5mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
MPL-AL5030-2R2
Monolithic Power Systems Inc.
- Inductance
- 2.2 µH
- Current
- 8.2 A
- DCR
- 12.3mOhm
- Size
- 0.217" L x 0.209" W (5.50mm x 5.30mm)
MPL-AL5050-100
Monolithic Power Systems Inc.
- Inductance
- 10 µH
- Current
- 4.8 A
- DCR
- 37mOhm
- Size
- 0.217" L x 0.209" W (5.50mm x 5.30mm)
MPL-AL6050-2R2
Monolithic Power Systems Inc.
- Inductance
- 2.2 µH
- Current
- 12 A
- DCR
- 8.3mOhm
- Size
- 0.260" L x 0.252" W (6.60mm x 6.40mm)
MPL-AL6050-3R3
Monolithic Power Systems Inc.
- Inductance
- 3.3 µH
- Current
- 10.1 A
- DCR
- 11.5mOhm
- Size
- 0.260" L x 0.252" W (6.60mm x 6.40mm)
MPL-AL6050-4R7
Monolithic Power Systems Inc.
- Inductance
- 4.7 µH
- Current
- 7.5 A
- DCR
- 16.5mOhm
- Size
- 0.260" L x 0.252" W (6.60mm x 6.40mm)
MPL-AL6060-100
Monolithic Power Systems Inc.
- Inductance
- 10 µH
- Current
- 6.9 A
- DCR
- 24mOhm
- Size
- 0.260" L x 0.252" W (6.60mm x 6.40mm)
MPL-AL4020-R68
Monolithic Power Systems Inc.
- Inductance
- 680 nH
- Current
- 8.7 A
- DCR
- 7.5mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
MPL-AL5050-8R2
Monolithic Power Systems Inc.
- Inductance
- 8.2 µH
- Current
- 5.8 A
- DCR
- 28mOhm
- Size
- 0.217" L x 0.209" W (5.50mm x 5.30mm)
MPL-AL5050-5R6
Monolithic Power Systems Inc.
- Inductance
- 5.6 µH
- Current
- 6.8 A
- DCR
- 20mOhm
- Size
- 0.217" L x 0.209" W (5.50mm x 5.30mm)
MPL-AL4020-1R0
Monolithic Power Systems Inc.
- Inductance
- 1 µH
- Current
- 7.9 A
- DCR
- 10.1mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
MPL-AL4020-1R2
Monolithic Power Systems Inc.
- Inductance
- 1.2 µH
- Current
- 7.4 A
- DCR
- 12.2mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
MPL-AL4020-R82
Monolithic Power Systems Inc.
- Inductance
- 820 nH
- Current
- 8.4 A
- DCR
- 9mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
MPL-AL4020-1R5
Monolithic Power Systems Inc.
- Inductance
- 1.5 µH
- Current
- 6.4 A
- DCR
- 14.5mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
MPL-AL4020-R47
Monolithic Power Systems Inc.
- Inductance
- 470 nH
- Current
- 9.2 A
- DCR
- 6.2mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
MPL-AL5030-R56
Monolithic Power Systems Inc.
- Inductance
- 560 nH
- Current
- 13.2 A
- DCR
- 3.92mOhm
- Size
- 0.217" L x 0.209" W (5.50mm x 5.30mm)
MPL-AL5030-1R0
Monolithic Power Systems Inc.
- Inductance
- 1 µH
- Current
- 11.2 A
- DCR
- 6.5mOhm
- Size
- 0.217" L x 0.209" W (5.50mm x 5.30mm)
MPL-AL5030-1R8
Monolithic Power Systems Inc.
- Inductance
- 1.8 µH
- Current
- 8.8 A
- DCR
- 10.5mOhm
- Size
- 0.217" L x 0.209" W (5.50mm x 5.30mm)
MPL-AL6050-1R2
Monolithic Power Systems Inc.
- Inductance
- 1.2 µH
- Current
- 14.6 A
- DCR
- 5.3mOhm
- Size
- 0.260" L x 0.252" W (6.60mm x 6.40mm)
MPL-AL6060-5R6
Monolithic Power Systems Inc.
- Inductance
- 5.6 µH
- Current
- 9.4 A
- DCR
- 13mOhm
- Size
- 0.260" L x 0.252" W (6.60mm x 6.40mm)
MPL-AL6050-1R0
Monolithic Power Systems Inc.
- Inductance
- 1 µH
- Current
- 16.2 A
- DCR
- 4.3mOhm
- Size
- 0.260" L x 0.252" W (6.60mm x 6.40mm)
MPL-AL5030-4R7
Monolithic Power Systems Inc.
- Inductance
- 4.7 µH
- Current
- 5.3 A
- DCR
- 33mOhm
- Size
- 0.217" L x 0.209" W (5.50mm x 5.30mm)
MPL-AL6060-150
Monolithic Power Systems Inc.
- Inductance
- 15 µH
- Current
- 5.8 A
- DCR
- 35mOhm
- Size
- 0.260" L x 0.252" W (6.60mm x 6.40mm)
| Product | Inductance | Current | DCR | Size | Package | Actions |
|---|---|---|---|---|---|---|
MPL-AL4020-4R7 Monolithic Power Systems Inc. | 4.7 µH | 3.65 A | 52.2mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-AL4020-2R2 Monolithic Power Systems Inc. | 2.2 µH | 5.5 A | 21.5mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-AL4020-3R3 Monolithic Power Systems Inc. | 3.3 µH | 4.4 A | 34.5mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-AL5030-2R2 Monolithic Power Systems Inc. | 2.2 µH | 8.2 A | 12.3mOhm | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 2-SMD | |
MPL-AL5050-100 Monolithic Power Systems Inc. | 10 µH | 4.8 A | 37mOhm | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 2-SMD | |
MPL-AL6050-2R2 Monolithic Power Systems Inc. | 2.2 µH | 12 A | 8.3mOhm | 0.260" L x 0.252" W (6.60mm x 6.40mm) | 2-SMD | |
MPL-AL6050-3R3 Monolithic Power Systems Inc. | 3.3 µH | 10.1 A | 11.5mOhm | 0.260" L x 0.252" W (6.60mm x 6.40mm) | 2-SMD | |
MPL-AL6050-4R7 Monolithic Power Systems Inc. | 4.7 µH | 7.5 A | 16.5mOhm | 0.260" L x 0.252" W (6.60mm x 6.40mm) | 2-SMD | |
MPL-AL6060-100 Monolithic Power Systems Inc. | 10 µH | 6.9 A | 24mOhm | 0.260" L x 0.252" W (6.60mm x 6.40mm) | 2-SMD | |
MPL-AL4020-R68 Monolithic Power Systems Inc. | 680 nH | 8.7 A | 7.5mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-AL5050-8R2 Monolithic Power Systems Inc. | 8.2 µH | 5.8 A | 28mOhm | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 2-SMD | |
MPL-AL5050-5R6 Monolithic Power Systems Inc. | 5.6 µH | 6.8 A | 20mOhm | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 2-SMD | |
MPL-AL4020-1R0 Monolithic Power Systems Inc. | 1 µH | 7.9 A | 10.1mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-AL4020-1R2 Monolithic Power Systems Inc. | 1.2 µH | 7.4 A | 12.2mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-AL4020-R82 Monolithic Power Systems Inc. | 820 nH | 8.4 A | 9mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-AL4020-1R5 Monolithic Power Systems Inc. | 1.5 µH | 6.4 A | 14.5mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-AL4020-R47 Monolithic Power Systems Inc. | 470 nH | 9.2 A | 6.2mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-AL5030-R56 Monolithic Power Systems Inc. | 560 nH | 13.2 A | 3.92mOhm | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 2-SMD | |
MPL-AL5030-1R0 Monolithic Power Systems Inc. | 1 µH | 11.2 A | 6.5mOhm | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 2-SMD | |
MPL-AL5030-1R8 Monolithic Power Systems Inc. | 1.8 µH | 8.8 A | 10.5mOhm | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 2-SMD | |
MPL-AL6050-1R2 Monolithic Power Systems Inc. | 1.2 µH | 14.6 A | 5.3mOhm | 0.260" L x 0.252" W (6.60mm x 6.40mm) | 2-SMD | |
MPL-AL6060-5R6 Monolithic Power Systems Inc. | 5.6 µH | 9.4 A | 13mOhm | 0.260" L x 0.252" W (6.60mm x 6.40mm) | 2-SMD | |
MPL-AL6050-1R0 Monolithic Power Systems Inc. | 1 µH | 16.2 A | 4.3mOhm | 0.260" L x 0.252" W (6.60mm x 6.40mm) | 2-SMD | |
MPL-AL5030-4R7 Monolithic Power Systems Inc. | 4.7 µH | 5.3 A | 33mOhm | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 2-SMD | |
MPL-AL6060-150 Monolithic Power Systems Inc. | 15 µH | 5.8 A | 35mOhm | 0.260" L x 0.252" W (6.60mm x 6.40mm) | 2-SMD |
