PA4309.124NLT

Pulse Electronics

120 µH• 3.2 ANonstandard

PA4309.152NLT

Pulse Electronics

1.5 µH• 20 ANonstandard

PA4309.153NLT

Pulse Electronics

15 µH• 9.3 ANonstandard

PA4309.184NLT

Pulse Electronics

180 µH• 2.6 ANonstandard

PA4309.222NLT

Pulse Electronics

2.2 µH• 20 ANonstandard

PA4309.224NLT

Pulse Electronics

220 µH• 2.3 ANonstandard

PA4309.274NLT

Pulse Electronics

270 µH• 2.12 ANonstandard

PA4309.333NLT

Pulse Electronics

33 µH• 6.2 ANonstandard

PA4309.394NLT

Pulse Electronics

390 µH• 1.75 ANonstandard

PA4309.472NLT

Pulse Electronics

4.7 µH• 15 ANonstandard

PA4309.473NLT

Pulse Electronics

47 µH• 5.2 ANonstandard

PA4309.562NLT

Pulse Electronics

5.6 µH• 14.5 ANonstandard

PA4309.563NLT

Pulse Electronics

56 µH• 4.6 ANonstandard

PA4309.564NLT

Pulse Electronics

560 µH• 1.45 ANonstandard

PA4309.684NLT

Pulse Electronics

680 µH• 1.32 ANonstandard

PA4309.822NLT

Pulse Electronics

8.2 µH• 11.5 ANonstandard

PA4309.823NLT

Pulse Electronics

82 µH• 3.9 ANonstandard

PA4309.824NLT

Pulse Electronics

820 µH• 1.2 ANonstandard

PA4309.332NLT

Pulse Electronics

3.3 µH• 19 ANonstandard

PA4309.334NLT

Pulse Electronics

330 µH• 1.9 ANonstandard

PA4309.102NLT

Pulse Electronics

1 µH• 20 ANonstandard

PA4309.223NLT

Pulse Electronics

22 µH• 7.5 ANonstandard

PA4309.682NLT

Pulse Electronics

6.8 µH• 13.5 ANonstandard

PA4309.683NLT

Pulse Electronics

68 µH• 4.2 ANonstandard

PA4309.474NLT

Pulse Electronics

470 µH• 1.6 ANonstandard

Product	Inductance	Current	DCR	Size	Package	Actions
PA4309.124NLT Pulse Electronics	120 µH	3.2 A	452mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.152NLT Pulse Electronics	1.5 µH	20 A	22mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.153NLT Pulse Electronics	15 µH	9.3 A	68mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.184NLT Pulse Electronics	180 µH	2.6 A	735mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.222NLT Pulse Electronics	2.2 µH	20 A	27mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.224NLT Pulse Electronics	220 µH	2.3 A	885mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.274NLT Pulse Electronics	270 µH	2.12 A	985mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.333NLT Pulse Electronics	33 µH	6.2 A	135mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.394NLT Pulse Electronics	390 µH	1.75 A	1.485Ohm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.472NLT Pulse Electronics	4.7 µH	15 A	38mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.473NLT Pulse Electronics	47 µH	5.2 A	182mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.562NLT Pulse Electronics	5.6 µH	14.5 A	40mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.563NLT Pulse Electronics	56 µH	4.6 A	236mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.564NLT Pulse Electronics	560 µH	1.45 A	2.241Ohm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.684NLT Pulse Electronics	680 µH	1.32 A	2.565Ohm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.822NLT Pulse Electronics	8.2 µH	11.5 A	48mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.823NLT Pulse Electronics	82 µH	3.9 A	326mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.824NLT Pulse Electronics	820 µH	1.2 A	3.51Ohm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.332NLT Pulse Electronics	3.3 µH	19 A	30mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.334NLT Pulse Electronics	330 µH	1.9 A	1.215Ohm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.102NLT Pulse Electronics	1 µH	20 A	19mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.223NLT Pulse Electronics	22 µH	7.5 A	98mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.682NLT Pulse Electronics	6.8 µH	13.5 A	42mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.683NLT Pulse Electronics	68 µH	4.2 A	298mOhm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
PA4309.474NLT Pulse Electronics	470 µH	1.6 A	1.755Ohm Max	0.504" L x 0.504" W (12.80mm x 12.80mm)	Nonstandard	View PDF
